Boyd Coddington Wheels

Boyd Coddington
Cast Series

Set of 4 wheels...
17" $1140
18" $1500
20" $1940

Wheel Sizes
17x7, 17x8, 17x10**
18x7, 18x8, 18x9*, 18x10***
20x8.5, 20x10*

* Add $10 per wheel
** Add $15 per wheel
*** Add $20 per wheel

Wheel Features:

Soft-rolled single lip hoop
Polished finish
Custom built to order
Machined and assembled in USA
a-356 center construction
Hub Centric
Exacting Tolerances
Available in 5 lug & 6 lug

Available in 5-lug & 6-lug (6 lug has 6 spokes)

RWD and FWD applications available

Backspace / Offset
Available in 1/8-inch Increments

size	min		max
	in	mm	in	mm

17x7	4.0	0	5.25	32
17x8	4.0	-13	6.25	44
17x10	4.0	-38	8.25	70
18x7	4.0	0	5.25	32
18x8	4.0	-13	6.25	44
18x9	4.0	-25	7.25	57
18x10	4.0	-38	8.25	70
20x8.5	4.0	-19	6.75	51
20x10	4.0	-38	call	call

If you want assistance in selecing wheel size or backspacing, please contact us with your
Wheel Fitment Questions

Wheel Order Terms

Order
